Powerlift 300
The Powerlift 300 is perfect for any commercial
application that requires up to 300 pounds of lifting capacity.
Dumbwaiter installs in hours, not days.
We custom build each dumbwaiter to give you the
largest car possible. Maximum car size for the
Powerlift 300 is 30" x 30" x 36" High outside dims
(28" x 28" x 34" High clear inside)
Click Above to Download our
Powerlift 300 Spec Sheet.
The Powerlift 300 Commercial Dumbwaiter
is perfect for Restaurants.
PRICES
2 Stop Powerlift 300 Commercial Dumbwaiter $7,395.00
3 Stop Powerlift 300 Commercial Dumbwaiter $8,950.00
4 Stop Powerlift 300 Commercial Dumbwaiter $10,595.00
5 and 6 Stop Powerlift 300 Commercial Dumbwaiter units available please call for prices.
THE ABOVE PRICES DO NOT INCLUDE THE COST OF SHIPPING OR SALES TAX (when required).
300 Lbs Capacity.
We custom build each dumbwaiter to give you the
largest car possible. Maximum car size for the
Powerlift 300 is (30" x 30" x 36" High)
**Discuss Car options with your salesperson**
NOTE: Maximum car sizes quoted are based on a cubic inch equation, but the width, depth and height dimensions are customizable within that equation. For example, you can choose a car size of 30" x 24" by 42" High, usually at no additional charge.
Dumbwaiter installs in hours, not days.
UL Listed Elevator/Dumbwaiter controller. (UL#233908)
Dumbwaiter car can be open on any 3 sides at no additional charge.
Call / send buttons, door interlocks, and door safety switches furnished.
Adjustable limits. NOTE: The limits are preset to your
specs, but are easily adjustable in the field.
All low voltage wiring is prewired with plugs for easy installation.
1 HP - 220 volt motor, or 240 volt, or 480 volt
3 phase motor.
Bottom or top motor mount.
Size 40 roller chain.
(3125 lbs tensile breaking strength)
Pillow block top fixture.
Top and bottom final limits.
Powder coated rail assembly, trolley, and car.
Keyed on / off switch available locks the dumbwaiter to keep children or unauthorized personnel from operating machine.
50Hz motor for European markets available.
Powder coated car panels available.
Car gates, slide-up or bi-parting, available.
Metal access and hoist way doors available.
Emergency stop switches available.
Car here lights available.
Car shelves available.
Stainless steel cars available.
Stainless steel units available.
Click Above to Download our
2 Stop Powerlift 300 Questionnaire Sheet.
We'll use your answers to generate shop drawings for your approval. If you have any questions regarding the Questionnaire, feel free to call or email.
Click Above to Download our
3 Stop Powerlift 300 Questionnaire Sheet.
We'll use your answers to generate shop drawings for your approval. If you have any questions regarding the Questionnaire, feel free to call or email.
Click Above to Download our
4 Stop Powerlift 300 Questionnaire Sheet.
We'll use your answers to generate shop drawings for your approval. If you have any questions regarding the Questionnaire, feel free to call or email.
Powerlift MJ-500
Each unit is custom made to your requirements. So be it Floor loading, Motor on top, you name it will do our best to make it happen.
The MJ-500 is built to be Stand the Test of Time.
The MJ-500 has been used in so many different applications, for clean rooms, explosion proof environments, restaurants, you name it we have probably done it.
Click Above to Download our
Powerlift MJ-500 Spec Sheet.
The MJ-500 is our largest commercial dumbwaiter we make. Max car size of 36" x 36" x 48" high, and a 500Lbs lifting capacity.
PRICES
2 Stop Powerlift MJ-500 Commercial Dumbwaiter $9,850.00
3 Stop Powerlift MJ-500 Commercial Dumbwaiter $13,150.00
4 Stop Powerlift MJ-500 Commercial Dumbwaiter $15,750.00
5 and 6 Stop Powerlift MJ-500 units available please call for prices.
THE ABOVE PRICES DO NOT INCLUDE THE COST OF SHIPPING OR SALES TAX (when required).
500 Lbs Capacity.
We custom build each dumbwaiter to give you the
largest car possible. Maximum car size for the
Powerlift MJ-500 is (36" x 36" x 48" High)
**Discuss Car options with your salesperson**
NOTE: Maximum car sizes quoted are based on a cubic inch equation, but the width, depth and height dimensions are customizable within that equation. For example, you can choose a car size of 36" x 42" by 42" High, usually at no additional charge.
Dumbwaiter installs in hours, not days.
UL Listed Elevator/Dumbwaiter controller. (UL#233908)
Dumbwaiter car can be open on any 3 sides at no additional charge.
Call / send buttons, door interlocks, and door safety switches and 1 Emergency Stop Switch furnished.
NOTE: Additional Emergency Stop Switches are
available.
Adjustable limits. NOTE: The limits are preset to your
specs, but are easily adjustable in the field.
All low voltage wiring is prewired with plugs for easy installation.
1 HP - 208 volt, 240 volt, or 480 volt 3 phase motor comes standard with the MJ-500. A 1-1/2 HP 220 Volt 60Hz single phase motor is available.
Bottom or top motor mount.
Size 50 roller chain.
(4880 lbs tensile breaking strength)
Pillow block top fixture.
Top and bottom final limits.
Powder coated rail assembly, trolley, and car.
50Hz motor for European markets available.
Keyed on / off switch available, locks the dumbwaiter to keep unauthorized personnel from operating the unit.
Powder coated car panels available.
Slide Up, and Bi-parting car gates available.
Metal access and hoist way doors available.
Car here lights available.
Car shelves available.
Stainless steel cars available.
Stainless steel units available.
Click Above to Download our
2 Stop Powerlift MJ-500 Questionnaire Sheet.
Our Questionnaire Sheets are for you to fill out with all the information we need
to draw up a job card for your dumbwaiter. If you have any questions regarding the Questionnaire feel free to call or email us.
Click Above to Download our
3 Stop Powerlift MJ-500 Questionnaire Sheet.
Our Questionnaire Sheets are for you to fill out with all the information we need
to draw up a job card for your dumbwaiter. If you have any questions regarding the Questionnaire feel free to call or email us.
Click Above to Download our
4 Stop Powerlift MJ-500 Questionnaire Sheet.
Our Questionnaire Sheets are for you to fill out with all the information we need
to draw up a job card for your dumbwaiter. If you have any questions regarding the Questionnaire feel free to call or email us.
